• Type TP without counter-plate
• Type G with counter-plate

Spherical bearings are characterized by low assembly height and restraint free design. Permissible angle of rotation axy is 13%.

If angular rotations can occur during the assembly phase but not in operation spherical bearings type K11 / K12 (one PTFE pad only) can be used.

In case of possible angular rotations during operation second PTFE pad in the spherical part must be used, this is type K21 / K22.

The fixed spherical bearing type KF can only cover angular and rotational movem ents.

Pointed rocker bearings have the advantage of high applicable loads with at the same time small junction area. Permissible angle of rotation axy is 13.

If angular and rotational movements occur at the same time fixed bearings type PF are to be used. In case of additional horizontal displacements the pointed sliding bearing type PK1 / PK2 should be used.

For lift - off loads, tempor arily fixings, adjustable heights and many other cases and applications we can design and produce special tailor made solutions. Please do not hesitate to contact us!

For connection temperatures up to 550°C nearly all bearings types can be combined with a thermal separation type TT in sandwich design.
