  • Dhatri Infrastructure (P) Ltd. Flat sliding bearings

    If no angular rotations can occur this type is mostly recommended.

    • Type TP without counter-plate
    • Type G with counter-plate
  • Dhatri Infrastructure (P) Ltd. Spherical bearings

    Spherical bearings are characterized by low assembly height and restraint free design. Permissible angle of rotation axy is 13%.

    If angular rotations can occur during the assembly phase but not in operation spherical bearings type K11 / K12 (one PTFE pad only) can be used.

    In case of possible angular rotations during operation second PTFE pad in the spherical part must be used, this is type K21 / K22.

    The fixed spherical bearing type KF can only cover angular and rotational movem ents.

  • Dhatri Infrastructure (P) Ltd. Pointed rocker bearings

    Pointed rocker bearings have the advantage of high applicable loads with at the same time small junction area. Permissible angle of rotation axy is 13.

    If angular and rotational movements occur at the same time fixed bearings type PF are to be used. In case of additional horizontal displacements the pointed sliding bearing type PK1 / PK2 should be used.

  • Dhatri Infrastructure (P) Ltd. Special type bearings

    For lift - off loads, tempor arily fixings, adjustable heights and many other cases and applications we can design and produce special tailor made solutions. Please do not hesitate to contact us!

  • Dhatri Infrastructure (P) Ltd. High temperature bearings

    For connection temperatures up to 550°C nearly all bearings types can be combined with a thermal separation type TT in sandwich design.

  • Dhatri Infrastructure (P) Ltd. Roller bearings

Technology Partner

Technology Partners:PG Systemtechnik KG,Dhatri Infrastructure (P) Ltd.

PG Systemtechnik GmbH & Co. KG, Germany was founded by Wilfried Naumann and Klaus Sasserath. Both have many years know - how in manufacturing, design and sales of PTFE bearings.

PG Systemtechnik is based with its production facilities and administration in the town Erkelenz which is located in the very west of Germany.

Under the brand name PGslide® the whole range of PTFE sliding bearings for power plants, pipe constructions and all types of civil engineering is produced. Bearing types are flat sliding supports, spherical bearings, pointed rocker bearings and custom tailored bearings.

PGslide® sliding bearings with PTFE (brand name e.g.Teflon®) as sliding material are used in applications which carry heavy even extreme loads, but at the same time have to move freely in two or three dimensions.

Main fields of application are hot /cold or cryogenic pipe systems, huge steelwork structures etc. as found in power plants, bridges or other petrochemical plant constructions.

PG Systemtechnik also supplies a variety of PTFE products such as semi-finished and finished parts–from easy shapes to high sophisticated designs, which can be integratedinto your own products.

A unique offer is PTFE sheets, rods and pads in special bearing and bridge bearing quality-supervised by independent testing authorities.

In addition PG Systemtechnik can offer design and calculation of sliding bearings and accessories as well as calculation of the connection to / or for on site structure.

On customers request additional services such as: assembly and installation instructions, training on site, installation by professional fitting and installation companies can be made.
